MCG | Power Sockets
This MCG Tool will Generates a power socket with minimal effort!.
Supported with 3dsmax 2016 - 2024
installation :
to install run 3dsmax in the menu go to " Scripting " then " Install Max Creation Graph ( . mcg) package "
UI :
Unit : shows the current file units.
Slot (1-10) Type: choose between 28 different power switches and sockets.
Slot (1-10) Flip ? : flip the current selected type.
Material : choose between standard, physical, Vray and corona material.
Assign Material : assign the selected material type to the tool.
Usage :
in the create panel go to geometry then choose "3D | RnD" category
like any other geometry after choosing "3DRnD_Power sockets" click on the view port and the Escalator will be created.
and if you right click on the type dropdown it will select none.
please note that the maximum amount of slots are 10, some types uses 2 slots so you may end up with less than 10 different types depending of the chosen types.
Subscribe to my YouTube channel:
follow me on instagram :
https://www.instagram.com/3d_r.n.d/
This software is provided on an "as is" basis, without warranty of any kind, express or implied, including without limitation, any implied warranties of merchantability, The entire risk as to the quality and performance of the software is borne by you, and it is your responsibility to ensure that it does what you require it to do prior to using it, The author is not responsible for any indirect, special, incidental, or consequential damages of any character including, without limitation, damages for loss of goodwill, Work stoppage, computer failure or malfunction, or any and all other commercial damages or losses.
Copyright : © 2009-2023 3D | R.n.D, All rights reserved
Author : Bayan Al Safadi
an MCG file (Max Creation graph) to easily create Power Sockets
